Sigma 3-16P - Page 60

Version 06/2007, Rev. 1.15 of 16/09/2011 - sb page 60 of 75
Translation of the original operating manual
Part no.
Description Max. speed
(rpm)
Max.
gravitational
field (x g)
17100 Round carrier for 1 round bottom tube approx. 100 ml,
max. Ø 45.5 x 85 - 105 mm, e.g. no. 15100, 15103, 15106,
1 set = 2 pcs.
17101 Round carrier for 1 round bottom tube 100 ml,
max. Ø 45.5 x 85 - 105 mm, e.g. no. 15100, 15102, 15102,
15103, 15106, 1 set = 2 pcs.
17125 Adapter for 1 bottle with flat bottom and screw cap 125 ml,
max. Ø 51 x 90 - 120 mm, e.g. no. 15125, 1 set = 2 pcs.
11132 Swing-out rotor 28 x 15 ml complete, no. 11133, incl. 2
sets buckets no. 13104, 2 sets round carriers no. 17015
and 28 PS-tubes 15 ml no. 15023,
max. radius 15.5 cm, min. radius 4.5 cm
5 000 4 332
11224 Swing-out cytology rotor complete, incl. 2 sets buckets no.
13224, 4 inserts no. 15223. The buckets with object
carriers could be locked in 90° position,
max. radius 11.3 cm, min radius 6.9 cm
3 000 1 137
11136



Drum rotor for 6 cassettes no. 14000, 14002, 14020,
14021, for reaction vials (max. 60/192 pcs.), incl. lid no.
17826,
max. radius 7 cm, min. radius 3 cm
Attention!
The vessels could be damaged at speeds exceeding
13,000 rpm!
13 000 13 226
14000 Casset, suitable for 20 reaction vials 0.25/0.4 ml no.
15014, 1 set = 2 pcs.
14002 Casset, suitable for 10 reaction vials 1.5/2.0 ml, e.g. no.
15008, 15040, 1 set = 2 pcs.
14020 Casset, suitable for 10 PCR-vials 0.2 or 0.5 ml,
1 set = 2 pcs.
14021 Casset, suitable for 32 PCR-tubes 0.2 ml, e.g no. 15042 or
4 strips with max. 8 tubes 0.2 ml, 1 set = 2 pcs.
11135 Swing-out rotor 24 x 1.5/2.0 ml, incl. 3 sets buckets no.
13124, for e.g. reaction vials no. 15008, 15040,
incl. hermetic aluminium lid no. 17879,
max. radius 7.4 cm, min. radius 3.5 cm
12 500 12 927
12154 Angle rotor 24 x 1.5/2.0 ml, for e.g. reaction vials no.
15008, 15040, incl. hermetic aluminium lid no. 17829,
max. radius 8.2 cm, min. radius 5 cm, angle 45°
14 500 19 275
12131 Angle rotor 30 x 1.5/2.0 ml, for e.g. reaction vials no.
15008, 15040, incl. hermetic aluminium lid no. 17848,
max. radius 10 cm, min. radius 6.7 cm, angle 45°
13 200 19 480
12349 Angle rotor 48 x 1.5/2.0 ml, for reaction vials, e.g. no.
15008, 15040, incl. aluminium hermetic lid no. 17349,
max. radius 10.0 cm, min. radius 6.5 cm
13 000 18 894
12115 Angle rotor, for 12 PCR-strips with 8 tubes 0.2 ml, e.g no.
15042, incl. hermetic aluminium lid no. 17875,
max. radius 9.8 cm, min. radius 7.2 cm, angle 45°
14 000 21 475
