AM 441 S-DIAS ANALOG MIXED MODULE ±10 V
Page 14 26.07.2023
5.2 Reference Output Specifications
Number of channels
1
Reference voltage
+10 V
Allowable output current
maximum 10.0 mA (< HW version 3.5)
maximum 16.7 mA (≥ HW version 3.5)
Allowable load per potentiometer
input
2.50 mA (< HW version 3.5)
4.17 mA (< HW version 3.5)
4.0 mA (< HW version 3.5)
2.4 mA (< HW version 3.5)
Allowable capacitive load
maximum 100 nF
Short circuit protection
yes
Accuracy
±0.5 %
5.3 Analog Output Specifications
Number of channels
4
Output range
-10 … +10 V
Output value
-10,000 ... +10,000
Resolution
12-bit (ca. 5 mV / LSB)
Refresh time for all channels
≥ 500 µs (corresponds to the S-DIAS cyclic time)
Output voltage capacity
> 5 kΩ
Allowable capacitive load
maximum 100 nF
Short circuit protection
yes (1 min.)
Settling time
50 µs (63 % of the end value)
100 µs (86 % of the end value)
250 µs (99 % of the end value)
Output precision
±0.5 % of maximum output value
