S-DIAS ANALOG MIXED MODULE ±10 V
AM 441
26.07.2023
Page
17
5.5
Miscellaneous
Article number
20
-
017
-
441
Standard
UL 508 (E247993)
Approbations
UL, cUL, CE
5.6
Environmental Conditions
Storage temperature
-20 ... +85 °C
Environmental temperature
0 ... +60 °C
Humidity
0-95 %, non-condensing
Installation altitude above sea
level
0-2000 m without derating
> 2000 m up to a maxi
mum of 5000 m with derating o
f the maximum
environmental temperature b
y 0.5 °C per 100 m
Operating conditions
pollution degree 2
EMC resistance
in accordance with EN 61000-6-2 (indu
strial area)
EMC noise generation
in accordance with EN 61000-6-4 (indu
strial area)
Vibration resistance
EN 60068-2-6
3.5 mm from 5-8.4 Hz
1 g from 8.4-150 Hz
Shock resistance
EN 60068-2-
27
15 g
Protection type
EN 60529
IP20
18
20
Table of Contents
Table of Contents
4
Introduction
7
Target Group/Purpose of this Operating Manual
7
Important Reference Documentation
7
Contents of Delivery
7
Basic Safety Directives
8
Symbols Used
8
Disclaimer
10
General Safety Directives
11
Software/Training
12
Standards and Directives
13
Directives
13
EU Conformity Declaration
13
Type Plate
14
Technical Data
15
Analog Inputs Specifications ±10 V or Potentiometer Inputs 0-100
15
Reference Output Specifications
16
Analog Output Specifications
16
Electrical Requirements
17
Miscellaneous
19
Environmental Conditions
19
Mechanical Dimensions
20
Connector Layout
21
Status Leds
22
Applicable Connectors
22
Label Field
23
Wiring
24
Wiring Example
24
Note
25
Connection Variants
26
Voltage Measurement of Not Potential-Free Voltage Sources
26
Voltage Measurement of Potential-Free Voltage Sources
27
Voltage Measurement with a Potentiometer
28
Connection to Analog Outputs
29
Assembly/Installation
30
Check Contents of Delivery
30
Mounting
31
Expanded Timing Modes (FW Version ≥ V02.00)
33
Speed Mode
33
Time-Offset Mode
33
Supported Cycle Times
35
Cycle Times below von 1 Ms (in Μs)
35
Cycle Times Equal to or Higher than 1 Ms (in Ms)
35
Addressing
36
V01.20)
36
Firmware - HW Class Addressing (FW Version ≥ V02.00)
39
Transport/Storage
44
Storage
44
Maintenance
45
Service
45
Repair
45
Disposal
45
Hardware Class AM441
46
General
47
Communication Interfaces
48
