SIGMATEK AM 441 User Manual

S-DIAS ANALOG MIXED MODULE ±10 V AM 441
26.07.2023 Page 15
5.4 Electrical Requirements
Voltage supply from S-DIAS bus
+5 V
Current consumption on the
S-DIAS bus (+5 V supply)
typically 50 mA
maximum 55 mA
Voltage supply from S-DIAS bus
+24 V
Current consumption on the
S-DIAS bus
(+24 V power supply)
typically 40 mA (without load on
reference output and analog out-
puts)
typically 60 mA (reference output
loaded with 4x 4 k and maximum
load on the analog outputs)
typically 70 mA (reference output
loaded with 4x 2k4 kand maximum
load on the analog outputs)
typically 50 mA (without load on
reference output and analog out-
puts)
maximum 80 mA (reference output
loaded with 4x 4 k and maximum
load on the analog outputs)
maximum 95 mA (reference output
loaded with 4x 2k4 kand maximum
load on the analog outputs)
Short circuit in analog inputs
typically an additional 30 mA per channel on a +24 V supply
INFORMATION
If this S-DIAS module is connected to an S-DIAS supply module with
several S-DIAS modules, the total current of the modules used must be
determined and checked.
The total current of the +24 V supply cannot exceed 1.6 A!
The total current of the +5 V supply cannot exceed 1.6 A!
The specification for the current can be found in the module-specific
documentation under "Electrical Requirements".
