SIGMATEK AM 441 User Manual

AM 441 S-DIAS ANALOG MIXED MODULE ±10 V
Page 46 26.07.2023
AI[1-4] cut off
frequency
Property
In this client, the cutoff frequency for the software low pass filter is set. Value
setting options are:
0
1000 Hz
1
500 Hz
2
250 Hz
3
100 Hz
4
50 Hz
5
25 Hz
6
10 Hz
AI[1-4] minimal
value
Property
This value indicates the minimum value for the channel. If -10 V is measured
at the channel, this value is output in the software. The range of the meas-
urement values are defined by the setting in the clients I[1-4]_Min + AI[1-
4]_Max.
AI[1-4] maximal
value
Property
This value indicates the maximum value for the channel. If +10 V is meas-
ured at the channel, this value is output in the software. The range of the
measurement values are defined by the setting in the clients I[1-4]_Min +
AI[1-4]_Max.
AO[1-4] minimal
value
Property
Minimum output value AO[1-4]. If this value is written to the respective
channel server, the module outputs -10 V
AO[1-4] maxi-
mal value
Property
Maximum output value AO[1-4]. If this value is written to the respective
channel server, the module outputs +10 V.
Analog Input [1-
4]
Input
Analog input 1-4, status query over read(). An open input returns -
2147483632 in the hardware class.
Analog Output
[1-4]
Output
Analog output [1-4].
17.2 Communication Interfaces
ALARM
Downlink
With this downlink the corresponding alarm class can be placed via the
hardware editor.
