AM 441 S-DIAS ANALOG MIXED MODULE ±10 V
Page 34 26.07.2023
12 Addressing
12.1 Firmware HW Class Addressing (FW Version V01.00 V01.20)
The address allocation defined here applies to the FW versions V01.00, V01.10 and
V01.20. for FW version V02.00, see 12.2.
Address
(hex)
Size
(bytes)
Access Type
Description
0000
128
w
Cyclic Data for Firmware
0000
2
w
Analog output 1
0002
2
w
Analog output 2
0004
2
w
Analog output 3
0006
2
w
analog output 4
0080
128
r
Cyclic Data for the HW class
0080
2
r
status
Bit 0 24 V DC not OK
Bit 1 not synchronized
Bit 2 FLASH calibration data CRC error
Bit 3 FLASH calibration data CRC error
Bit 4 invalid calibration data
Bit 5-15 reserved
0082
2
r
Analog input 1
0084
2
r
Analog input 2
0086
2
r
Analog input 3
0088
2
r
Analog input 4
