SIGNODE BPT-H32
3.2 Function
● Feed the strap manually through the seal (1).
● Guide the strap start (5) around the packaged
goods and through the seal again, then bend
it over.
● Tensioning by feed wheel principle (4).
● Sealing by notching (2) the seal.
● Strap cut with knife(3).
● You can choose between three operating modes
(Section 4.2):
● Manual (standard/factory setting)
● Semi-automatic
● Fully automatic
● The tensioning force is adjustable (Section. 4.3).
● The tools can be operated with the strap widths 19, 25 and 32 mm (Section 7).
If straps with a strap thickness of 0.60 mm (< 0.80 mm) are used (see section 4.6).
3.3 Scope of delivery
For strapping tool BPT-H32: ● Battery Li-Ion ProCORE 18 V / 4.0 Ah Part no 2187.025
or: ● Battery Li-Ion ProCORE 18 V / 8.0 Ah Part no 2187.015
● Battery charger GAL 1880 CV EU Part no 2188.020
or for USA version: ● Battery Li-Ion ProCORE 18 V / 4.0 Ah Part no 2187.026
● Battery Li-Ion ProCORE 18 V / 8.0 Ah Part no 2187.016
● Battery charger (US) 1880 Part no 2188.021
or for Japan version: ● Battery charger GAL 1880 CV (JP) Part no 2188.022
or for Australia version: ● Battery charger GAL 1880 CV(AUS) Part no 2188.023
Tool kit consisting of: ● Screwdriver Torx T20 Part no 1821.901.010
– battery with 4.0 Ah for mobile strapping
– battery with 8.0 Ah for permanently suspended tool
4
1
3
2
5
