SII LP-1010 - Page 223

14-8
■Clearing paper jam in manual feed drawer
1 (When DOOR 6 is displayed) Open the top cover (Door 6).
2 Open the cutter door.
Loosen the two knobs and open the cutter door
gently.
OPEN DOOR 6 , 9 , 4
REMOVE PAPER
OPEN DOOR 9 , 4
REMOVE PAPER
Top cover (Door 6)
Knob
Cutter door
(Door 5)
