System commands
AP04-RS485/SIKONETZ5
Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 22 of 38
6.2 Restore factory settings
In some instance, for instance for evaliuating the position indicator, it may be useful to
restore the device's factory settings. This may de done as follows:
Access
Coding
Factory settings are restored
Manually




all parameters


only standard parameters


only bus parameters
Service protocol
S
11100
all parameters
11101
only standard parameters
11102
only bus parameters
SIKONETZ5
0xA0
1
all parameters
2
only standard parameters
5
only bus parameters
Table 10: Access to factory settings
6.3 Alignment travel
The position indicator is aligned in the factory and is, therefore, fully functioning.
The following steps must be carried out for additional alignment:
1. Start alignment (see Table 11: Start access to alignment)
The following is displayed:


The value can vary by +/- 1.
2. Rotate the position indicator's shaft counter-clockwise at the speed of << 1 rpm .
The value will slowly change until 103.
3. If this value is finally exceeded, the alignment process will be completed.
The position indicator enters normal operation, which is shown on the display unit.
4. Calibrate the position indicator (see chapter 6.1 Calibration)
It is not unusual that the position value cannot be displayed at first following alignment
travel and "" displayed instead. The correct value will be displayed after calibration.
Alignment can be started as follows.
Access
Coding
Manually




Service protocol
S
00100
SIKONETZ5
0xC3
1
Table 11: Start access to alignment
