Communication via SIKONETZ5
AP04-RS485/SIKONETZ5
Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 37 of 38
Parameter
Name
Access
Format
Description
no.acc. to
chapter 4
Adr.
[hex]
0xFD
Error
Integer32
(see chapter 8.5 Error
telegram)
0xFE
Actual position
ro
Integer32
Actual position (see chapter
3.1 Operating modes)
0xFF
Set point
rw
Integer32
Set point
Table 18: Parameter description SIKONETZ5
8.9 Examples of access
8.9.1 Example: Read parameter
With read commands the data range shall be set to value 0.
Reading the parameter target window1 of node address 1:
Read command: 0x00
Node address: 0x01
Parameter address: 0x20 Target window1
Data: 0x00 00 00 00
Telegram from master to slave
1
st
byte
2
nd
byte
3
rd
byte
4
th
byte
5
th
byte
6
th
byte
7
th
byte
8
th
byte
9
th
byte
10
th
byte
Command
Node
address
Parameter
address
CW
Data
Check
sum
0x00
0x01
0x20
0x00
0x00
0x00
0x00
0x00
0x00
0x21
Reply telegram from slave
1
st
byte
2
nd
byte
3
rd
byte
4
th
byte
5
th
byte
6
th
byte
7
th
byte
8
th
byte
9
th
byte
10
th
byte
Command
/ Reply
Node
address
Parameter
address
SW
Data
Check
sum
0x00
0x01
0x20
0x00
0x01
0x00
0x00
0x00
0x05
0x25
