3.4.1.8 Options
Menu


Parameter display
Parameter no.
acc. To chapter 4
Description

9
Key enable time
Value range: 1 … 60

11
Key function release for Reset (calibration)
Selection:
: Reset enabled via key
: Reset disabled via key

10
Key function enable for incremental
measurement
Selection:
: Incremental measurement enabled via key
: Incremental measurement disabled via key

32
Formula for calculating the differential value
Selection:
: Differential value = actual position -
set point
: Differential value = actual position -
actual position

8
Operating mode of the display
Selection:
: Display of absolute actual position and
set point
: Display of absolute actual position and
differential value
: Display of angle values (0 … 360°)

System commands
Selection:
: set all parameters to default (restore
factory settings)
: only standard parameters to default
: only bus parameters to default
: start equalization
Table 6: Options menu
3.4.2 Parameterization via interface
The position indicator can be completely parameterized in the SIKONETZ5 protocol via the
RS485 interface (see chapter 8.8 Parameterization via SIKONETZ5).
