Parameter description
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 16 of 38
No.
Name
Selection /
value
Default
Description
S
C
P
7
Write reply
parameter to
set point
0 … 2
0
SIKONETZ5:
This parameter defines the reply to
the Write set point command
0 = Set point
1 = Actual value
2 = Differential value
Service protocol:
no function
S
2
P
8
Operating
mode
0 … 2
0
Type of position value display
0 = absolute position display
1 = differential value
2 = Modulo
(see chapter 3.1 Operating modes)
S
1
P
9
Key enable
time
1 … 60
15
Display / key control:
Time in seconds how long the
key must be held down until
configuration starts
S
1
P
10
Key function
enable
Incremental
measurement
0 … 1
1
Display / key control:
0 = incremental measurement
function disabled
1 = incremental measurement
function enabled
S
1
P
11
Key function
enable reset
0 … 1
1
Display / key control:
0 = Calibration (reset) function via
key disabled
1 = Calibration (reset) function via
key enabled
S
1
P
12
LED 1 red
0 … 1
1
Red LED 1 function:
0 = Off
1 = position-dependent display
(On)
If the position-dependent display
for both LEDs is switched off the
LEDs can be enabled by the control
word (see chapter 8.3.4 Control
word).
S
1
P
13
LED 1 green
0 … 1
1
Green LED 1 function:
0 = Off
1 = position-dependent display
(On)
If the position-dependent display
for both LEDs is switched off the
LEDs can be enabled by the control
word (see chapter 8.3.4 Control
word).
S
1
P
14
LED blinking
0 … 1
0
LED blinking function:
0 = LED display glows constantly
(when On)
1 = LED display glows (when On)
S
1
P
