Display and Control Keys
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 5 of 38
2.2 LCD display
The The display range is limited to -19999 … 99999. Values outside this
range are displayed with "".
With supply voltage applied to the position indicator, the 1st line shows the actual position
and the 2nd line shows the set point with factory settings. The values displayed are
determined by the operating mode.
Direction indicators (arrows) support positioning.
The battery symbol is shown with a critical or insufficient battery status.
With incremental measurement function activated, the incremental measurement symbol
is shown.
2.2.1 Extended display range
If values below -99999 are to be displayed, this can be realized by means of the control word,
Bit3 in the operational mode with SIKONETZ5 protocol. If this bit is set and the value to be
displayed is in the range between -19999 … -99999, then the negative sign and the figure
with the highest value are blinking alternately. If the value range drops below -99999,
"" will be displayed.
2.3 LED display
In the basic state (factory setting), the LED has the following meaning:
Actual position
LED
State
In target
window1
green
on
red
off
Outside target
window1
red
on
green
off
Table 1: LED displays
2.4 Keys
Pressing the key enables or disables the incremental measurement function.
Pressing the key starts calibration (see chapter 6.1 Calibration) and acknowledges a
pending error (see chapter 5.2 Errors).
Pressing the key starts the parameterization mode (see chapter 3.4 Parameterization of
the position indicator).
