Functional Description
AP04-RS485/SIKONETZ5
Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 9 of 38
3.4 Parameterization of the position indicator
The position indicator can be completely parameterized via the keys as well as via the bus
interface.
3.4.1 Manual parameterization
3.4.1.1 Starting parameterization
After applying supply voltage, the position indicator will be on the uppermost level of the
menu structure (default/delivery state).
By actuating the key, the set node address and baud rate is displayed. Parameterization
starts after expiry of the release time (see chapter 4 Parameter description Parameter no.
9).
3.4.1.2 Value input
With value input via the keys, the display range is limited to -19999 …
99999. When entering values beyond this range via SIKONETZ5 or the
service protocol, "" will be displayed when you call up the parameter.
Enter values via the key and the key. Confirm values entered by pressing the key.
- decimal place selection key
- Value input key
3.4.1.3 Value selection
For some parameters you can select values from a list.
Direct value input is not possible there.
Pressing the key, the value can be selected from the list. By pressing the key, the
selection is confirmed.
