Communication via Service Protocol
AP04-RS485/SIKONETZ5
Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 24 of 38
Bit
Meaning
Value = 0
Value = 1
6
Deviation
Actual position < = set
point
Actual position >set point
7
Error
not present
present
The cause of the error must be
removed and acknowledged.
8
Position value output
dynamic
freezed
9
Position value =
incremental measurement
off
on
10
reserved
-
-
11
Battery status (warning)
all right
critical
12
reserviert
-
-
13
key
not actuated
actuated
14
key
not actuated
actuated
15
key
not actuated
actuated
Table 13: System Status Word
7.4 Service protocol commands list
Command
Length
Reply
Description
Parameter
no.acc. to
chapter 4
Ay
2/17
"AP04_SN5_
zWVxxx>"
Device type / software version
y=0: hardware version; z = H
y=1: software version; z = S
35
By
2/10 dez
"±xxxxxxx>"
Diagnosis
y=3: Battery voltage [1/100 V]
34
Ey
2/11
"±xxxxxxxx>"
Output values
±xxxxxxxx = decimal value in
increments
y=0: Current set point
2
y=1: Position with incremental
measurement formation
-
y=2: Position with calibration
-
y=3: Calibration value
26
y=5: Offset
25
Fy±xxxxxxxx
11/2
">"
Enter values
±xxxxxxxx decimal value in
increments
y=0: Target position (volatile)
2
y=3: Calibration value
26
y=5: Offset
25
