Communication via Service Protocol
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 25 of 38
Command
Length
Reply
Description
Parameter
no.acc. to
chapter 4
Gyy
3/7
"xxxxx>"
Output 2-byte value
yy = Address
xxxxx = decimal value
yy=00: APU / spindle pitch
24
yy=01: Display divisor
0 = 1
1 = 10
2 = 100
3 = 1000
16
yy=02: Display divisor application
17
yy=03: Decimal places
0 = 0
1 = 0.0
2 = 0.00
3 = 0.000
4 = 0.0000
15
yy=04: Target window 1
27
yy=05: Target window 2
28
yy=06: Visualization of target
window2
29
yy=07: Positioning mode
30
yy=08: Loop length
31
yy=09: Direction indication function
0 = On
1 = inverted
2 = Off
18
yy=10: Key enable time
Range 1 – 60 seconds
9
yy=11: Key function enable reset
(Calibration)
0 = Function disabled via key
1 = Function enabled via key
11
yy=12: Key function enable
incremental measurement
0 = Function disabled via key
1 = Function enabled via key
10
yy=13: Display orientation
0 = 0°
1 = rotated by 180°
19
yy=14: LED blinking
0 = Off
1 = On
14
yy=15: reserviert
-
yy=16: LED red
0 = Off
1 = On
12
