Siko AP04 User Manual

Communication via Service Protocol
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 26 of 38
Command
Length
Reply
Description
Parameter
no.acc. to
chapter 4
yy=17: LED green
0 = Off
1 = On
13
yy=18: Displayed value 2
nd
display
line
0 = set point
1 = Off
20
yy=19: Differential value calculation
0: Differential value = actual
position – set point
1: Differential value = set point –
actual position
32
yy=20: reserved
-
yy=21: Baud rate RS485
0 = 19200
1 = 57600
2 = 115200
4
yy=22: Node address
3
yy=23: Response delay
36
Hyyxxxxx
8/2
">"
Enter 2-byte value
yy = Address
xxxxx = decimal value
yy=00: APU / spindle pitch
24
yy=01: Display divisor
16
yy=02: Display divisor application
17
yy=03: Decimal places
15
yy=04: Target window 1
27
yy=05: Target window 2
28
yy=06: Visualization of target
window2
29
yy=07: Positioning mode
30
yy=08: Loop length
31
yy=09: Direction indication function
18
yy=10: Key enable time
9
yy=11: Key function enable reset
(Calibration)
11
yy=12: Key function enable
incremental measurement
10
yy=13: Display orientation
19
yy=14: LED blinking
14
yy=15: reserved
-
yy=16: LED red
12
yy=17: LED green
13
