Communication via Service Protocol
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 27 of 38
Command
Length
Reply
Description
Parameter
no.acc. to
chapter 4
yy=18: Displayed value 2
nd
display
line
20
yy=19: Differential value calculation
32
yy=20: reserved
-
yy=21: Baud rate RS485
4
yy=22: Node address
3
yy=23: Response delay
36
K
1/2
">"
Software reset
-
L
1/2
">"
Calibration
(see chapter 6.1 Calibration)
-
R
1/2
"xy"
Output system status word (hex)
for the meaning of the individual
bits see Table 13: System Status
Word
x = High Byte
y = Low Byte
Sxxxxx
6/2
">"
Reset device to basic state /
System commands
x=00100: Start alignment (see
chapter 6 System commands)
x=11100: all parameters into basic
state
Caution! All parameter classes will
be reset. After restart, the factory
settings will be active, this applies
to bus protocol and baud rate as
well.
x=11101: only standard parameters
into basic state
x=11102: only bus parameters into
basic state
x=11103: Acknowledge error
x=11104: Acknowledgement target
window1 static (description see
chapter 3.2 Position monitoring)
x=11105: activate bootloader
Ty
2/2
">"
Enter sense of rotation
y=0: i sense of rotation (cw)
y=1: e sense of rotation (ccw)
23
