Siko AP04 User Manual

Parameter description
AP04-RS485/SIKONETZ5 Date: 24.11.2016 Art. No. 86218 Mod. status 351/16 Page 17 of 38
No.
Name
Selection /
value
Default
Description
S
C
P
15
Decimal
places
0 … 4
0
Display:
Input of decimal places
0 = 0
1 = 0.0
2 = 0.00
3 = 0.000
4 = 0.0000
S
1
P
16
Display
divisor
0 … 3
0
Display:
Divisor by which the display
accuracy is reduced compared with
the measurement resolution.
0 = 1
1 = 10
2 = 100
3 = 1000
S
1
P
17
Display
divisor
application
0 … 1
0
Display / transmission accuracy:
0= The display divisor is applied to
the set point and actual position
of interface and display unit.
1= The display divisor is only
applied to the display unit. The
values are transferred via the
interface with undivided
resolution.
S
1
P
18
Direction
indication
function
0 … 2
0
Display:
The direction indicators show the
direction of shaft adjustment
required to arrive at the set target
window 1.
0 = On
1 = inverted
2 = Off
S
1
P
19
Display
orientation
0 … 1
0
Display:
Display orientation
0 = 0°
1 = rotated by 180°
S
1
P
20
Displayed
value
2
nd
display
line
0 … 1
0
Display:
Parameter to be displayed in the
2nd line of the display.
0 = set point
1 = OFF
S
1
P
21
Programming
mode
configuration
0 … 1
0
SIKONETZ5:
0 = programming not locked
1 = locking of programming
depends on the programming mode
Service protocol:
no function
S
1
P
