REKORD Operating manual - English
10 Copyright Silca 2 007
4 ACCESSORIES PROVIDED
To ensure trouble-free working with the REKORD, it is advisable to always have certain spare parts on
hand. It is advisable to always have a tool box containing: tools, cutting tools, brushes, belts and small
replacement parts.
REKORD is supplied with a full range of accessories.
The accessories provided by Si lca are all that is ne cessary to ca
rry out the op erations fo
r which the
machine is designed.
Fig. 5
ADHESIVE LABEL
“DANGEROUS MOBILE PARTS”
STEEL PIN Ø 1,20
2 pcs
STEEL PIN Ø 1,70
2 pcs
STEEL BAR
2 pcs
5X20 FUSES (2 pcs)
4 Amps rapid (230V)
8 Amps rapid (120V)
2,5 mm ALLEN KEY
3 mm ALLEN KEY
19 mm SPANNER
10 mm SPANNER
CUTTING TOOL
UNCLAMPING PIN
ADJUSTING BAR
2 pcs
4 mm ALLEN KEY
5 mm ALLEN KEY
ATTENTION
DANGEROUS
MOBILE PARTS
