Description of work station
The key-cutting machine needs only one operator, who has the following controls at his/her disposal:
- Switch on the lamp by activating the main switch (O) located on the right-hand side of the machine.
- The motor on switch (N), located on the left-hand side of the machine has a warning light to show
that the key-cutting machine is live.
-
Ca
rriage movement lever (D)
-
Ca
rriage
handle lever (A)
-
Ca
rriage
release lever (B)
-
Gaug
e knob (G).
Fig. 10 
5.8 Graphics
ABD
N
G
THE USE OF
PROTECTIVE GOGGLES
IS COMPULSORY
ATTENTION
DANGEROUS
MOBILE PARTS
Place the adhesive label “Dangerous
mobile parts” (ch .4, p age 10 ) as
shown.
