Simaudio Moon 240i - DAC, Phono, and Signal Specifications; Power, Dimensions, and Fuse Replacement

25
Phono section
Input Impedance / Capacitance 47kΩ / 100pF
Gain 40dB
Input overload @ 40dB 58mV RMS
Signal-to-noise ratio (full scale @ 40dB) 104dBr
Frequency Response 20Hz - 20kHz (±0.5dB)
Crosstalk @ 1kHz -95dB
IMD 0.01%
THD (20Hz - 20kHz) 0.001%
DAC section
Digital Input Impedance (S/PDIF) 75 ohms @ 0.5 Volts
DSD Data Rates
(2.8224MHz), Double (5.6448MHz) & Quadruple
(11.2896)
DSD Sample Rates DSD64, DSD128 & DSD256 (via USB only)
PCM Bit-depth range 16 - 32 bits (32-bit via USB only)
PCM Sampling Frequency Rates 44.1 - 384kHz (352.8 & 384kHz via USB only)
Remote Control Full-Function (CRM-3)
Display Type OLED
Power Consumption @ idle 44 watts
Power Consumption @ Standby 11 watts
AC Power Requirements 120V / 60Hz or 240V / 50Hz
Shipping Weight 24 lb. / 11 Kg.
Dimensions (W x H x D, inches / cm.) 16.9 x 3.5 x 14.4 / 42.9 x 8.9 x 36.6
Fuse Replacement:
The 120V version use a 4A fast blow fuse (3AG size).
The 230V version use a 2A fast blow fuse (3AG size).
If you require the RS-232 codes for your MOON 240i, please visit the "Contact Us" page and complete the
"Information request" form on our website at www.simaudio.com
