Simonelli MUSICA - Hydraulic Circuit Components and Servicing

Ed. 01 of 12/2015
6.1
Service Manual
inDeX
6. HYDRAULIC CIRCUIT ............ 6.1
6.1 PUMP DISASSEMBLY ................6.2
6.2 REPLACING THE COFFEE VALVE .....6.4
6.3
FLOWMETER........................6.6
6.4 HOT WATER VALVE ..................6.8
6.4.1 DISASSEMBLY
OF HOT WATER NOZZLE .....6.10
6.5 STEAM NOZZLE ....................6.10
6.6 WATER TANK ......................6.15
6.6.1 REPLACEMENT
OF THE FLOAT..............6.15
6.6.2 REMOVAL OF THE
MAGNETIC SENSOR.........6.16
6.6.3 REMOVAL OF THE
TANK MICROSWITCH........6.16
6.7 REMOVAL OF THE
PRESSURE SWITCH ................6.17
6. HYDraulic circuiT
TOOLS NEEDED:
