7
CAUTION
• Never use the pressure washer to draw in water contaminated with solvents (e.g.
paint thinners, gasoline, oil, etc.).
• Dirt in the water inlet will damage the unit. To avoid this risk, we recommend checking
• Always prevent debris from being drawn into the unit by using a clean water source
Water Supply (Cold Water Only)
Only draw water through the unit. For use with cold water supply only. Water hose must
be at least a 1/2” (13 mm) in diameter. Flow rate of water supply must not fall below 2
GPM (gallons per minute) [9.1 lpm (litres per minute)]. Flow rate can be determined by
running the water for one minute into an empty 5-gallon (19 L) container. The water supply
temperature must not exceed 104° F(40° C).
ASSEMBLY INSTRUCTIONS
1
3 4
2
Insert handle frame into pressure washer
and align the holes. Insert three nuts into
the front, and insert the screws from behind
as shown. Tighten the screws.
Assemble the gun holster. Assemble the high-pressure hose to the
gun assembly.
Attach the hand crank onto the hose reel.
Assemble the extension hose to the reel.
To Next Page
