3-10
This section contains the instructions for the end-of-life replacement of the 4098-9746 CO
Replacement Cartridge (CORC), in the CO SSD Bases (Carbon Monoxide Smoke Sensor and
Detector Bases). Replacement is necessary due to normal component degradation over time. It is
standard maintenance for the CO SSD Bases in order to prolong normal function without requiring
base replacement.
Note: During installation, you may be exposed to live circuits - attention required to ensure
personal safety and to avoid product damage.
Model number reference:
Model Name
4098-9746 CORC Replacement
4098-9797 CO SSD Sensor Base
4098-9798 CO SSD Sounder Base
Removing the expired CORC
1. Remove sensor head (not shown) and set aside for later re-installation.
2. Insert a fine blade screwdriver into the slot, as shown below.
3. Gently free the CORC from the sensor base by pushing straight in. Do not pry. Remove the
CORC and dispose.
Figure 3-9. Removing the CORC from the Sensor Base
______________________________________________________________________________
Continued on next page
4098 TrueAlarm Sensor Bases,
Continued
CRS Replacement
Instructions
