Simplex 4100 Series User Manual

Page 12 of 60
1.1.2.3.4 Extra Device
Description:
A device is located on the addressable loop that is addressed at a location that is not programmed.
Possible causes:
The panel has identified a device/card at an address that is not in the panel programming. Refer to the Extra
Device section of Device Faults (Page 20).
A card/device may be incorrectly addressed bringing up an Extra Device fault and the programmed device‟s
address will display “Points defined but not inserted.”
1.1.2.3.5 IDNet Dipswitch Settings
1. Devices are supplied with DIPSWITCH switch ALL ON (set to 0)
2. DIPSWITCHES are labeled 1 to 8
 Switch 1 = MUST BE ON (OFF disables card communications)
 Switch 2 = 64
 Switch 3 = 32
 Switch 4 = 16
 Switch 5 = 8
 Switch 6 = 4
 Switch 7 = 2
 Switch 8 = 1
3. Turn Switch OFF to add the above number to the address.
Examples:
 Address 5 = Switch 6 & 8 OFF all others ON.
 Address 23 = Switch 4, 6, 7 & 8 OFF others ON.
NOTE - This is reverse of how the addressable devices addresses’ are set.
[Refer to section 1.1.3.9 – page 19]
