Page 27 of 60
2.2 4100-Family General Crash Codes Table
CRASH_UNEXPECTED
<CRASH UNEXPECTED>
CLASS S CRASH
Unexpected crash due to possible
bug in executive software (System
PROM)
– Call Headquarters Technical Support at once!
CRASH_INTERNAL_RAM_BAD
<INTERNAL RAM ERROR>
CLASS S CRASH
CRASH_EXTERNAL_RAM_BAD
<EXTERNAL RAM ERROR>
CLASS S CRASH
CRASH_BAD_RAM
<Bad or missing RAM chip>
CLASS E CRASH
- RAM chip defective, improperly inserted, or missing
- Not enough memory for Job or bad RAM chip
- CFIG chip is blank
CRASH_BAD_CODE
<CODE Checksum Error>
CLASS E CRASH
Code checksum error
System PROM is defective, NOT
programmed or inserted improperly
- Will occur with Rev 4.02 and earlier when used with 8096BH
microprocessor change indicator „E.‟ Check 9
th
character of FPO
number on U9. If „E‟ then Rev 4.03, or higher system executive is
required. Also see FSB-386R
- The CFIG format (Panel Programmer) used is incompatible with
the panel EXEC installed
CRASH_BAD_CONST
<K_SEG checksum error>
CLASS E CRASH
K_SEG CHECKSUM ERROR
- System PROM U34 is defective, NOT programmed, NOT
properly inserted, or missing.
- Error 32 can be caused by a defective, un-programmed or
improperly inserted flash chip
CRASH_BAD_CFIG
<CFIG checksum error>
CLASS E CRASH
CFIG checksum error – CFIG PROM
is defective, not programmed, or
inserted improperly
- Can be caused by CFIG RAM selected by dipswitch SW1-2, but
CFIG RAM is not installed in the U45 socket
- There has been a large number of AMD AM28F010 and
AM28F020 Flash chip failures
CRASH_CFIG_FMT
<Invalid CFIG Format>
CLASS E CRASH
Indicates that the CFIG format number is incompatible with the
version of executive software (System PROM). Check
programmer disk Rev number against Rev number on the label
of the System PROM.
Update System PROM to Rev of current software by burning a
new system executive PROM
