Simplex 4100 Series User Manual

Page 19 of 60
 Devices are supplied with DIPSWITCH set to 255
 DIPSWITCHES are labeled 1 to 8 (left to right)
 Switch 1 = 1
 Switch 2 = 2
 Switch 3 = 4
 Switch 5 = 8
 Switch 6 = 16
 Switch 7 = 32
 Switch 8 = 128
 Turn Switch ON to add the above number to the address. Examples:
 Address 10 = Switch 2 & 5 ON all others OFF
 Address 105 = Switch 1, 4, 6 & 7 ON others OFF
 The highest IDNet device address is 250.
 The highest MAPNet device address is 127.

1.1.3.1.10 End of Line Resistors
For a comprehensive pocket reference guide contact your local Simplex® branch
4090-9001
Supervised IAM
Current Limited
6.8kΩ
4.7kΩ & 1.8kΩ
4090-9101
Monitor ZAM
3.3kΩ
4090-9118
Relay IAM with T-Sense
Current Limited
6.8kΩ
4.7kΩ & 1.8kΩ
4090-9120AU
6 Pt I/O Module
Current Limited
6.8kΩ
4.7kΩ & 1.8kΩ
2190-9156
Mapnet Monitor ZAM
3.3kΩ
2190-9164
Mapnet Signal ZAM
10kΩ
4100 EWIS
WIPs
10kΩ
4100 8pt Monitor Card
Conventional Zone Card
3.3kΩ
4100 6 Signal Card
Signal Card
10kΩ
4100 24-pt IO Card
Pluggable Resistors on card
2.2kΩ Input
20Ω Output
