Simplex 4100 Operation

1-4
TrueAlert Appliances can have one of the following status conditions:
• Normal
• Missing (trouble)
• Wrong appliance (trouble)
• Short (trouble – isolator only)
VNACs have the following status information:
• On/off
• Disabled (trouble)
• Manual override (trouble)
• Priority (2-15)
The TrueAlert Controller can have one of the following card-level status
conditions:
• Card Missing Trouble
• Wrong Card Trouble
• Channel 1 Class A Trouble
• Channel 2 Class A Trouble
• Channel 3 Class A Trouble
• Channel 1 Communications Failure
• Channel 2 Communications Failure
• Channel 3 Communications Failure
• Positive Earth
• Negative Earth
• AC Fail
• Battery Low/Disconnected
• Running on Depleted Battery
• Channel 1 Short Circuit Trouble
• Channel 2 Short Circuit Trouble
• Channel 3 Short Circuit Trouble
• Hardware Configuration Mismatch Trouble
• Battery Charger Trouble
• TrueAlert Channel Controller Trouble
• Common Class A Trouble
Continued on next page
Version 9.X System Description,
Continued
TrueAlert Appliances
VNAC Status
TrueAlert Controller
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
