Simplex 4100 Operation

1-11
The Display First Alarm alarm list feature (which enables the automatic display
of the first alarm) is configurable via the Programmer (disabled by default). If
this option has been programmed for your panel, the Operator Interface Panel
shows the first (oldest) alarm whenever a single or multiple alarm conditions is
reported. The panel LCD display displays the first alarm instead of the “alarm
totals” screen display. The following figures demonstrate how a display might
appear during an alarm sequence if the Display First Alarm option is selected.
General Point Information Layout
The following screens shows a layout of the fields when displaying the first
alarm point information.
40 CHARACTER CUSTOM LABEL
POINT TYPE BANNER POINT STATUS
Single Event Unacked Alarm Point
EAST WING, THIRD FLOOR, HEAT
Shows unacked
Heat Detector FIRE ALARM
alarm point and
(Second line alternates once a second)
EAST WING, THIRD FLOOR, HEAT
alternates second line
Press <Alarm Ack> to acknowledge
with ack message
Single Event Acked Alarm Point
EAST WING, THIRD FLOOR, HEAT
Shows acked
Heat Detector FIRE ALARM
alarm point and
(Screen alternates once a second)
**FIRE** Press <Ack> to review.
alternates screen with
FIRE=1 PRI2=0 SUPV=0 TRBL=0
tally screen
Continued on next page
Operator Interface,
Continued
Display First Alarm
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
