Simplex 4100 Operation

3-5
Note: In order for Diagnostics to operate properly all appliances must
be inactive prior to diagnostic activation.
1. Use the following procedure to place the system in the Single Appliance
Test Mode to run the Manual Real Appliance Test.
2. Go to the Operator Interface Panel and enter the address of a TrueAlert
appliance assigned to a particular TrueAlert Addressable Controller.
3. Under the TrueAlert appliance’s FUNCTION screen, put the appliance into
Device Test Mode and verify that a TRUEALERT APPLIANCE TEST
MODE ACTIVE trouble is generated at the Operator Interface Panel (and
reported by Pseudo P230).
4. Wait a minimum of one to two minutes before testing appliances to ensure
that the diagnostics are active.
5. Activate the magnetic reed switch on the appliance and verify that the horn
appliances sound and that the strobe appliances blink at least once.
6. Under a TrueAlert appliance’s FUNCTION screen, take the TrueAlert
Addressable Controller out of Device Test Mode and verify the trouble clears.
(The trouble will clear automatically in eight hours.)
If more than one TrueAlert Addressable Controller is connected to the system
repeat the above procedure on the remaining controllers.
Manual Real Appliance Test
Procedure
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
