Simplex 4100 Operation

3-4
Note: In order for Diagnostics to operate properly all appliances must
be inactive prior to diagnostic activation.
Use the following procedure to activate all of the TrueAlert Appliance LEDs
assigned to a particular TrueAlert Addressable Controller.
1. Log on the 4100/4020 at the appropriate Access Level.
2. On the Operator Interface Panel, go to the TrueAlert appliance function
screen and turn on the appliance LEDs on the TrueAlert Addressable
Controller. Verify that all of the appliance LEDs assigned to the TrueAlert
Addressable Controller turn on. (The 4100/4020 display will remained
locked onto this screen for eight hours or until you turn off the LEDs.)
3. From the Operator Interface Panel display under the TrueAlert appliance
function screen, turn off the appliance LED’s on the TrueAlert
Addressable Controller.
If more than one TrueAlert Addressable Controller is connected to the system
repeat the above procedure on the remaining Addressable Controllers.
Appliance LED Activation
Procedure
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
