1-12
Multiple Event Unacked Alarm Points
EAST WING, THIRD FLOOR, HEAT
Show first unacked alarm
Heat Detector FIRE ALARM
event point information and
(Second line alternates once a second)
EAST WING, THIRD FLOOR, HEAT
alternate second line with
Press <Alarm Ack> to acknowledge
ack message
Multiple Event Display After Acking First Alarm Point
EAST WING, FOURTH FLOOR, SMOKE
First alarm acked;
Smoke Detector FIRE ALARM
show next alarm and
(Second line alternates once a second)
EAST WING, FOURTH FLOOR, SMOKE
alternate second line with
Press <Alarm Ack> to acknowledge
ack message.
Multiple Event Display After Acking Second (Last) Alarm
EAST WING, THIRD FLOOR, SMOKE
All alarms acked; alternate
Heat Detector FIRE ALARM
between first alarm point
(Screen alternates once a second)
**FIRE** Press <Ack> to review.
and the main tally screen.
FIRE=2 PRI2=0 SUPV=0 TRBL=0
Operator Interface,
Continued
Display First Alarm
(Continued)
firealarmresources.com
