Simplicity Broadmotor Series User Manual

9 Torque Generator Repair
Exploded View Diagram
9 - 2
20
17
14
13
15
11
8
9
10
9
21
9
4
3
22
6
1
5
2
9
16
2a
700
7
12
15 Pin
14 Spool
13 Sleeve
1 Screw, Cap, (7)
Plate, Spacer
9 Seal, O-ring (4)
11 Drive, Control End
Housing, Valve (for Inlet Relief Valve)12a
Housing, Power End2
Washer
Seal, Quad
Ring, Retaining
7 Drive, Power End
3
4
5
8
Shaft, Power End6
10 Gerotor
Washer22
Relief Valve S/A26
Plug27
O-ring28
Spacer, Spring (for Increased Input Torque) (4)30
Key, Woodruff (2)700
Spring, Centering (for Standard Input Torque) (6)
Ring, Retaining
Seal, Quad
Seal, Shaft (Lip Type)
O-ring (2)
16
17
18
19
Washer20
Plate, Spacer21
18a
12a
26
27
28
30
18a
18
Housing, Valve12
OUT
IN
AUX
Housing, Power End (bearings, needle type)2a
19
OUT
OUT
IN
AUX
IN
AUX
Not for Reproduction
