14 Transmission Tear-Down
Exploded View Diagrams
1 1 CASE SET, (K71E Only, See Ref. 20 for K71G)
2 2 BEARING, 28 x 15
3 1 TAPER PLUG, 1/8, (K71E Only)
4 1 BORE PLUG, 17, (K71E Only)
5 1 CAP, Oil, 20
6 1 FILTER
7 1 FITTING
8 1 SEAL
9 2 BEARING
10 2 SEAL
11 1 SCREW, Tapping, 8 x 25
12 18 SCREW, Tapping
13 1 SCREW, Tapping, 8 x 45
14 2 BOLT, 8 x 75”
15 3 RING, 47
16 2 BOLT, 10 x 12
17 2 PACKING, P18
18 1 MAGNET COMPLETE
19 1 MAGNET, Disk
20 1 CASE SET (B), (K71G Only, See Ref. 1 for K71E)
21 1 SEALANT
22 1 CASE, Lower
23 1 WASHER, Seal 10
24 2 PIPE, 13 x 11.3
25 1 CENTER CASE COMPLETE
26 1 VALVE, (A-1 SET)
27 2 VALVE, (A-2 SET)
28 2 KNOCK PIN, 15.5 x 30
29 1 PLUG, 16 x 25
30 1 PACKING
31 2 PIN, 8 x 14
32 1 PIN, 3 x 9.8
33 3 BOLT, 10 x 75
34 1 FILTER
35 1 CAP, (M40)
36 1 PACKING
37 2 CYLINDER BLOCK COMPLETE
38 1 PUMP SHAFT
39 2 RING, 17
40 1 BEARING, 6303
41 1 HOUSING
42 1 BEARING, 51207
43 2 BLOCK
44 1 WASHER, 18 x 31 x 1
45 1 SHAFT MOTOR
46 1 BEARING
47 1 MOTOR GEAR
48 1 SNAP RING, 20
49 1 RING, E15
50 1 PUMP CASE S/A
51 1 PUMP CASE COMPLETE
52 1 CHECK BALL RETAINER
53 1 HOLDER, (SEAT)
54 1 VALVE, (IMP COMPLETE)
55 2 PLUG
56 1 VALVE, (CHARGE COMPLETE)
57 1 PLUG, PT 1/8
58 2 CONNECTOR
59 2 PACKING, P16
K71 Hydrostatic Transmission
REF NO. QTY. DESCRIPTION
