Simplicity Broadmotor Series User Manual

12 - 3
12 Hand Controls Service
Exploded View Diagrams
1 1650157 1 BUTTON
2 1713995 1 GRIP
3 1918265 2 WASHER, 5/16
4 1676526 1 SPRING, Compression
5 1721866 1 QUADRANT & LEVER ASSEMBLY
6 1705249 3 SPACER
7 1922127 1 CAPSCREW, Hex Head, 5/16-18 x 1-3/4
8 1921977 1 CAPSCREW, Hex Head, 5/16-18 x 1-1/4
9 1919438 6 LOCKNUT, ESNA, 5/16-18
10 1722320 2 PIN, Cotter Locking
11 1922755 2 WASHER, 3/8
12 1708298 2 PIN, Round Head, Drilled, 3/8 x 1
13 1960033 1 HAIR PIN, Clip
14 1911386 1 WASHER, 3/4
15 1923325 4 CAPSCREW, Hex Head, 5/16-18 x 7/8
16 1704712 1 BRACKET
17 1721869 1 TUBE & ARMS ASSEMBLY
18 1704713 1 BRACKET & PINS ASSEMBLY
19 1704715 1 BRACKET
20 1934953 1 PUSH NUT, 5/16
21 1927609 1 ROLL PIN, 3/8 x 1
22 1721999 1 LATCH
23 1721959 1 ROD
Manual Lift Mechanism - Models with 44” Mower Deck
REF NO. QTY. DESCRIPTION
Not for Reproduction
