Simplicity Broadmotor Series User Manual

12 - 5
12 Hand Controls Service
Exploded View Diagrams
1 1916951 1 NUT, 1/2-13
2 1916966 1 LOCKWASHER, 1/2-13
3 1924361 2 WASHER, 1/2
4 1722412 2 SPACER
5 1708559 2 PULLEY
6 1924359 2 WASHER, 1/2
7 1722343 2 PULLEY, Guide
8 1722411 2 SPACER
9 1960245 1 CAPSCREW, Hex Head, 1/2-13 x 3
10 1703805 1 RING, Klipring
11 1708298 4 PIN, Round Head, Drilled, 3/8 x 1
12 1722436 2 CABLE
13 1922755 2 WASHER, 3/8
14 1722320 4 PIN, Cotter Locking
15 1650157 1 BUTTON
16 1713995 1 GRIP, Black
17 1918265 2 WASHER, 5/16
18 1676526 1 SPRING, Compression
19 1722413 1 QUADRANT & LEVER ASSEMBLY
20 1705249 3 SPACER
21 1922127 1 CAPSCREW, Hex Head, 5/16-18 x 1-3/4
22 1921977 1 CAPSCREW, Hex Head, 5/16-18 x 1-1/4
23 1721959 1 ROD
24 1721999 1 LATCH
25 1927609 1 ROLL PIN, 3/8 x 1
26 1934953 1 PUSH NUT, 5/16
27 1704715 1 BRACKET
28 1919438 8 LOCKNUT, 5/16-18
29 1923325 4 CAPSCREW, Hex Head, 5/16-18 x 7/8
30 1704713 1 BRACKET & PINS ASSEMBLY
31 1709926 1 TUBE & ARMS ASSEMBLY
32 1704712 1 BRACKET
33 1911386 1 WASHER, 3/4
34 1960033 1 PIN, Hair
Manual Lift Mechanism - Models with 50” Mower Deck
REF NO. QTY. DESCRIPTION
Not for Reproduction
