Simplicity Broadmotor Series - Page 141

13 - 3
13 Hood & Dashboard Service
Exploded View Diagram
1 10 PAL NUT, 1/4-20
2 1 AIR DUCT
3 1 MOLDING, Air Duct
4 1 PLUG, Hole, Electric Lift
5 1 DASH ASSY.
6 1 DASH, Lower
7 2 WASHER, Plain, 1/4
8 20 CAPSCREW, Hex Flange Hd, Whizlock, 1/4-20 x 5/8
9 1 BUSHING, Nylon
10 7 CAPSCREW, Taptite, 1/4-20 x 1/2
11 1 SUPPORT, Bulkhead, LH
12 10 NUT, Hex Nylon Lock, 1/4-20
13 1 SUPPORT, Bulkhead, RH
14 1 BULKHEAD
15 1 GROMMET, Wire Harness
16 1 GROMMET, Bulkhead
17 1 SIDE PANEL ASSY., LH
18 2 STRAP, Hood
19 2 WASHER, Special
20 2 NUT, Hex Nylon Lock, #10-24
21 1 GRILLE
22 2 HINGE, Hood
23 2 SPACER, Hood
24 2 SPACER
25 2 PIVOT, Hood
26 2 CAPSCREW, Taptite, 5/16-18 x 1
27 2 CLIP, Hairpin
28 2 CAPSCREW, Taptite, 5/16-18 x 5/8
29 1 SIDE PANEL ASSY
30 1 HOOD
31 2 PLUG
32 1 CAPSCREW, Taptite, 1/4-20 x 3/8
Hood, Grille, & Dash Group
REF NO. QTY. DESCRIPTION
Not for Reproduction
