1 General Information
Specifications
CONTROLS:
Steering 15" (38 cm) Steering Wheel
System: Gear and Sector, 1.25 turns Lock to
Lock
Clutch/ Location: Right Front
Brake Pedal Combination Clutch/Brake/Parking Brake
Pedal
Location Mower Lift Lever: Right Side
PTO Clutch: Electric, Dash Mounted
Hydrostatic Control-Single Lever Foot Pedal
Ignition Key Switch: On Lower Dash Panel
Throttle Lever On Dash Panel and Choke
Knob On Lower Dash Panel
Light Switch: On Dash Panel
Separate Indicator Lights for Safety
Interlock Switch: Operator Present,
PTO Disengaged,
Low Oil Pressure Warning Light, Hourmeter
DIMENSIONS:
Overall Length 70.25 in (178 cm)
Overall Width 35 in (88.9 cm)
Height To Top of Steering Wheel: 40 in (101.6 cm)
To Top of Engine Cover: 34 in (86.7 cm)
Wheel Base 50.75 in (129 cm)
Weight (apx..) Net: 424 lbs. (192 kg) w/o mower
536 lbs. (243 kg) w/mower
Shipping: 575 lbs. (261 kg) w/o mower
687 lbs. (312 kg) w/mower
Tractor Height
w/Snowcab 71.5 in (181 cm)
Tractor Length
w/Snowthrower est. 98 in (249 cm)
Tractor Length
w/Dozer Blade est. 94 in (239 cm)
50” MOWER: 12 GA.
Effective Cutting
Width 50 in Mower - 50 in (127 cm)
Overall Width
with Deflector 50 in Mower - 62 in (157.5 cm)
Weight 50 in Mower - 135 lbs. (61.4 kg)
Variable Cutting Ht. 1.0 - 3.6 in (3.2 to 8.0 cm)
Blade Arrangement Three Staggered Blades
Mower Drive V-Belt From Tractor Engine PTO Electric
Clutch
Spindle Bearings Lubricated and Sealed Ball Bearings
Lube Fitting Provided
44” MOWER: 12 GA.
Effective Cutting
Width 44 in Mower - 44 in (111.8 cm)
Overall Width
with Deflector 44 in Mower - 56 in (142.2 cm)
with Turbo 58" (147 cm)
Weight 44 in Mower - 112 lbs. (51 kg)
Variable Cutting Ht. 1.0 - 3.6 in (3.2 to 8.0 cm)
Blade Arrangement Three Staggered Blades
Mower Drive V-Belt From Tractor Engine PTO Electric
Clutch
Spindle Bearings Lubricated and Sealed Ball Bearings
Lube Fitting Provided
38” MOWER: 12 GA.
Effective Cutting
Width 38 in Mower - 38 in (96.5 cm)
Overall Width
with Deflector 38 in Mower - 49.5 in (125.7 cm)
with Turbo 38 in Mower - 51.5 in (131 cm)
Weight 38 in Mower - 100 lbs. (45 kg)
Variable Cutting Ht. 1.0 - 3.6 in (2.5 to 9.1 cm)
Blade Arrangement Two Blades
Mower Drive V-Belt From Tractor Engine PTO Electric
Clutch
Spindle Bearings Lubricated and Sealed Ball Bearings
Lube Fitting Provided
