16 Mower Deck Service
38” Mower Deck - Housing, Arbors, & Blades
1 2 NUT, Hex Flange, 9/16-8
2 4 WASHER, Belleville
3 1 PULLEY, LH
4 2 HUB ADAPTER, Pulley
5 2 COVER, Arbor Housing
6 4 BEARING
7 2 SPACER
8 2 GASKET, Foam
9 2 ARBOR HOUSING ASSY. (Incl. Ref. No. 10)
10 2 FITTING, Grease
11 4 NUT, Hex, 5/16-18
12 4 LOCKWASHER, 5/16
13 4 WASHER, Flat, 5/16
14 2 UPSTOP
15 4 WASHER, 3/8
16 1 PULLEY, RH
17 1 MOWER DECK HOUSING, 38” (Orange)
17 1 MOWER DECK HOUSING, 38” (Charcoal Grey)
18 2 WASHER
19 2 SHAFT, Arbor
20 2 SHIELD, Grass, Lower
21 1 BLADE, Mower, 16-1/8”
22 2 WASHER, Hex
23 2 WASHER, Spring
24 2 CAPSCREW, Hex, Hd, 7/16-14 x 1-1/4
25 4 CAPSCREW, Taptite, 5/16-18 x 1-1/2
26 1 BLADE, Mower, 22-1/4”
27 8 CAPSCREW, Taptite, 5/16-18 x 3/4
28 2 CARRIAGE BOLT, 1/4-20 x 7/8
29 2 PLUG, Hole
30 1 NUT, Push
31 2 WASHER, Plain
32 1 CLAMP
33 1 WASHER, 5/16
34 1 SPRING
35 2 LOCKWASHER, 1/4
36 2 NUT, Hex, 1/4-20 UNC
37 1 DEFLECTOR, Plastic
38 1 ROD, Deflector, Front
38” Mower Deck - Housing, Arbors & Blades
REF NO. QTY. DESCRIPTION
38” Mower Deck - Housing, Arbors & Blades
