16 - 5
16 Mower Deck Service
38” Mower Deck - Belt & Hitch Group
1 1 V-BELT
2 2 CAPSCREW, Hex Hd, 3/8-16 x 2-3/4
3 1 GUARD, Belt
4 4 WASHER, Plain, 3/8
5 1 SPACER
6 1 IDLER PULLEY (Incl. Ref. 5)
7 1 GRIP, Lever
8 1 CLUTCH LEVER ASSY. (Incl. Ref. Nos. 9 & 16)
9 1 FITTING, Grease
10 1 LOCKWASHER, 3/8
11 1 NUT, Hex, 3/8-16
12 1 SPRING
13 3 NUT, Hex Steel Lock, 3/8-16
14 1 NUT, Hex Flange, 2-Way Lock, 3/8-16
15 1 SPACER
16 2 BUSHING
17 2 WASHER, 3/8
18 2 WASHER, Plain, 13/32
19 2 SPACER
20 1 ROD, Latch
21 1 HITCH ASSY.
22 1 SPRING
23 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/2
REF NO. QTY. DESCRIPTION
38” Mower Deck - Belt & Hitch Group38” Mower Deck - Belt & Hitch Group
