16 Mower Deck Service
38” Mower Deck - Height Adjustment & Roller Group
1 2 NUT, Hex Flange Lock, 1/2-13
2 1 SHAFT ASSY., Roller
3 6 WASHER, Plain, 1-1/4
4 8 ROLLER
5 2 SPACER
6 1 BAR, Roller
7 1 NUT, Adjuster
8 2 LOCKWASHER, 3/8
9 2 NUT, Hex, 3/8-16
10 1 SLIDE
11 1 WASHER, Plain, 1/2
12 1 BOLT, Shoulder, 3/8-16
13 1 NUT, Push
14 1 WASHER, 5/8
15 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
16 2 STRAP, Mower Arm Assy.
17 6 CAPSCREW, Taptite, 5/16-18 x 3/4
18 5 WASHER, Plain, 13/32
19 1 CLIP, Pin, Safety
20 1 LINK ASSY., Lift
21 1 COTTER PIN
22 1 COTTER PIN
23 4 NUT, Hex, 5/16-18
24 4 LOCKWASHER, 5/16
25 1 BRACKET, Cutting Height
26 1 ARM, Rear, Mower, RH
27 4 CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
28 1 CRANK, Cutting Height
29 1 KNOB
30 1 PAL NUT
31 1 TRUNNION, Threaded
32 3 WASHER, 5/8
33 1 TRUNNION
34 1 PIN, Roll, 1”
35 1 WASHER, Detent
36 1 STRAP, Trunnion Retainer
37 2 NUT, Hex Jam, 1/2-13
38 1 TRUNNION
39 1 PIN, Clevis
40 1 ARM ASSY., Mower
41 1 INDICATOR, Cutting Height
42 1 WASHER, Flat, 5/16
43 1 PLATE, Support
44 1 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4
45 1 ROD, Adjustment
46 1 SPACER
47 1 NUT, Hex Flange, 3/8-16
38” Mower Deck - Height Adjustment & Roller Group
REF NO. QTY. DESCRIPTION
