16 - 11
16 Mower Deck Service
44” & 50” Mower Decks - Belt & Hitch
1 1 HITCH ASSY.
2 1 ROD, Latch
3 1 GRIP, Lever
4 2 NUT, Hex, 3/8-16
5 2 LOCKWASHER, 3/8
6 1 BELT STOP, Idler
7 14 WASHER, Plain, 13/32
8 2 SPACER
9 2 PULLEY, Idler (Incl. Ref. 8)
10 1 NUT, Hex Flange, 2-Way Lock, 3/8-16
11 4 BUSHING
12 1 SPRING
13 2 SPACER
14 2 FITTING, Grease
15 1 LEVER ASSY, Idler (Incl. Ref. Nos. 11 & 14)
16 1 CARRIAGE BOLT, 3/8-16 x 2
17 1 LEVER ASSY, Idler Arm (Incl, Ref. Nos. 11 & 14)
18 2 WASHER, 3/8
19 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
20 1 SPRING
21 1 CAPSCREW, Hex Hd, 3/8-16 x 3-1/2
22 2 NUT, Hex Steel Lock, 3/8-16
23 2 SPACER
24 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/2
25 1 SPRING
26 1 V-BELT, Arbor Drive, 44” Deck
26 1 V-BELT, Arbor Drive, 50” Deck
27 1 V-BELT, Mower Drive, 44” Deck
27 1 V-BELT, Mower Drive, 50” Deck
44” & 50” Mower Decks - Belt & Hitch
REF NO. QTY. DESCRIPTION
