16 - 15
16 Mower Deck Service
50” Mower - Height Adjustment & Rollers
1 2 NUT, Hex, 3/8-16
2 2 LOCKWASHER, 3/8
3 1 NUT, Adjuster
4 1 SHAFT ASSY, Roller, 50” (Incl. Ref. No. 11)
5 1 SLIDE
6 1 WASHER, Plain, 1/2
7 1 BOLT, Shoulder, 3/8-16
8 1 NUT, Hex Flange, 3/8-16
9 3 SPACER
10 9 ROLLER
11 2 NUT, Push
12 10 WASHER, Plain, 1-1/4
13 9 WASHER, Plain, 13/32
14 1 CLIP, Pin, Safety
15 1 LINK ASSY, Lift
16 1 COTTER PIN
17 2 NUT, Hex Flange Lock, 1/2-13
18 1 BAR, Roller
19 1 CRANK, Cutting Height
20 1 KNOB, Height Crank
21 1 PAL NUT
22 2 CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
23 1 ARM, Rear, Mower, RH
24 1 BRACKET, Cutting Height
25 2 LOCKWASHER, 5/16
26 2 NUT, Hex, 5/16-18
27 1 COTTER PIN
28 2 NUT, Hex Jam, 3/4-11
29 3 WASHER, 5/8
30 1 TRUNNION
31 1 PIN, Clevis
32 6 CAPSCREW, Taptite, 5/16-18 x 3/4
33 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
34 3 STRAP, Mower Arm Assy.
35 1 ARM ASSY., Mower
36 1 PIN, Roll, 1” Long
37 1 WASHER, Detent
38 1 TRUNNION
39 1 TRUNNION, Threaded
40 1 PLATE, Mower Support
41 1 INDICATOR, Cutting Height
42 1 WASHER, Flat, 5/16
43 4 CAPSCREW, Taptite, 5/16-18 x 1-1/4
44 1 UP-STOP, Mower
45 1 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4
46 1 ROD, Adjustment
47 1 SPACER
48 1 NUT, Hex Flange, 3/8-16
50” Mower - Height Adjustment & Rollers
REF NO. QTY. DESCRIPTION
