7 - 5
7 Electrical System Service
Exploded View Diagrams
1 1 HEADLIGHT ASSY. (Incl. Ref. Nos. 2, 3, 4, 5 & 6)
2 1 LENS, Headlight
3 2 BULB, Headlight, 12.8V
4 1 BEZEL, Headlight
5 2 HEAT SHIELD
6 2 SOCKET, Bulb
7 1 WIRE ASSY., Headlight
8 1 SWITCH, Seat, Operator Present
9 2 BUSHING, Snap, Small
10 1 BUSHING, Snap, Large (Kohler Models Only)
11 2 CABLE TIE
12 1 WIRE ASSY., Seat Switch
*13 1 WIRE HARNESS, Lower (Early Briggs & Stratton Models - See Footnote)
13 1 WIRE HARNESS, Lower (Kohler Models)
*13 1 WIRE HARNESS, Lower (Later Briggs & Stratton Models - See Footnote)
14 1 WIRE ASSY., Engine Ground
Electrical - Lower Harness
REF NO. QTY. DESCRIPTION
Footnotes:
* Briggs & Stratton Model Wire Harness Note: The Briggs & Stratton models listed below use lower wire har-
ness 1704377. All other Briggs & Stratton Models use lower wire harness 1718308.
1693052 S/N 00001-496
1693056 S/N 00001-01169
1693058 S/N 00001-74
1693060 S/N 00001-1169
1693062 S/N 00001-224
1693066 S/N 00001-51
1693068 S/N 00001-26
1693072 S/N 00001-28
Not for Reproduction
