7 - 7
7 Electrical System Service
Exploded View Diagrams
1 7 CAPSCREW, Plastite, #8-16 x 1/2
2 1 HOURMETER
3 1 INTERLOCK SWITCH, Cruise/Parking Brake
4 1 SWITCH, Headlight
5 5 BULB, Indicator Light
6 1 STRAP, Wire Retainer
7 1 BOOT, Insulator
8 1 BATTERY
9 1 TRAY, Battery
10 2 NUT, Plastic, 1/4-20
11 1 CABLE, Battery to Ground
12 1 HOSE, Battery, Drain
13 2 CAPSCREW, Hex Hd, 1/4-20 x 3/4
14 4 WASHER, Plain, 1/4
15 2 LOCKWASHER, 1/4
16 2 NUT, Hex, 1/4-20 UNC
17 1 HOLD DOWN, Battery
18 2 ROD, Battery Hold Down
19 1 COVER, Terminal
20 1 CABLE, Solenoid to Starter
21* 1 WIRE HARNESS, Main (Early Briggs & Stratton Models - See Footnote)
21 1 WIRE HARNESS, Main (Kohler Models)
21* 1 WIRE HARNESS, Main (Later Briggs & Stratton Models - See Footnote)
22 1 SWITCH, PTO Electric Clutch
23 1 CIRCUIT BREAKER
24* 1 IGNITION SWITCH, 5-Pin Plastic Body (Early Briggs Models - See Footnote)
24* 1 IGNITION SWITCH, 6-Pin, Plastic Body (Kohler Models and Later Briggs & Stratton Models -
See Footnote)
25 1 WIRE ASSY, Lock Light (All Briggs & Stratton Models)
26 1 NUT, Flange
27 2 KEY, Ignition
28 1 MODULE
29 1 SWITCH, Interlock, Clutch/Brake Pedal
30 1 WIRE ASSY.
31 1 WIRE ASSY.
32 1 SOLENOID
33 2 CAPSCREW, Hex Washer Hd, Plastite, 1/4-20 x 1/2
34 1 CABLE, Battery to Solenoid
35 2 LOCKWASHER, 5/16
36 2 NUT, Hex, 5/16-24
37 2 CAPSCREW, Taptite, #5-40 x 3/4
38 2 LOCKWASHER, 1/8
39 2 NUT, Machine Screw, #5-40
Electrical - Upper Harness
REF NO. QTY. DESCRIPTION
Footnotes:
* Briggs & Stratton Model Ignition Switch Note: The Briggs & Stratton models listed below use 5-pin plastic
ignition switch 1713845 and main wire harness 1715805. All other Briggs & Stratton Models use 6-pin plastic
ignition switch 1718305 & main wire harness 1718307.
1693052 S/N 00001-496
1693056 S/N 00001-01169
1693058 S/N 00001-74
1693060 S/N 00001-1169
1693062 S/N 00001-224
1693066 S/N 00001-51
1693068 S/N 00001-26
1693072 S/N 00001-28
