Dimensional drawing
118 mm (4.64")
115 mm (4.52")
8 mm
(0.31")
36.5 mm
(1.43")
28.5 mm
(1.12")
97.5 mm (3.83")
48.5 mm (1.91")
STBY
MODE AUTO
MENU
X
10
Dimensional drawing| AP44 Operator Manual
51
