Simrad AP44 User Manual

Introduction
The AP44 is a networked autopilot display and control unit.
The unit is compatible with a range of Navico autopilot computers,
including AC12N, AC42N, NAC-2, NAC-3 and SG05 autopilot
computers.
The AP44 systems include several modules that need to be
mounted in different locations on the vessel and that need to
interface with at least three different systems on the boat:
• The boat’s steering system
• The boat’s electrical system (input power)
• Other equipment onboard
All parts of the autopilot system must be installed and configured
according to supplied documentation prior to using the autopilot.
The following steps are required:
• Mechanical installation and wiring of all units. Refer to separate
documentation for the units
• Software setup of the system. Refer to "Software setup" on page 28
• Commissioning and setup of the autopilot computer. Refer to
the installation and commissioning documentation for your
autopilot computer
Manuals
The following documentation is available for the AP44 system:
• AP44 Operator manual (988-11189-00n) - this manual
•
AP44/IS42/Triton
2
Installation guide (988-11229-00n)
•
AP44/IS42/Triton
2
Mounting template (988-11230-00n)
• NAC-2/NAC-3 Autopilot computer Commissioning manual
(988-11233-00n)
• AC12N/AC42N Installation manual (988-10276-00n)
Ú
Note: The last digit in the part numbers is the document's
revision code. The latest version of all documents can be
downloaded from the product website on www.simrad-
yachting.com.
1
Introduction | AP44 Operator Manual
7

Simrad AP44 Specifications

General

Interface	NMEA 2000
Power Supply	12/24 V DC
Water Resistance	IPX6
Operating Temperature	-15°C to +55°C
Display Size	4.1 inches
Display Type	LCD
Control Type	Rotary dial and buttons
Operating Voltage	10-31.2 V DC
Control Modes	Auto, Nav, Wind
