10 |
Introduction | AP70/AP80 Installation Manual
AP80, Wheelmark-approved system example
¼ Note: For IMO approval, other equipment must be connected via an SI80 board located in an
SI80, AC80A, AC80S or AC85 computer.
TURN
MENUCMD
STBY AUTO N AV WORK
ALARM
T
12/24V DC
GYRO
COMPASS
ECDIS SYSTEM
AP80 CONTROL HEAD FU80
AC85
AD80/
SD80
AD80/
SD80
THRUSTER
CONTROL
RUDDER
CONTROL
12/24V DC
T
CD100A
CDI80
T
CAN BUS
DROP CABLES
NMEA 0183/
IEC 61162-1/
IEC 61162-2
TERMINATOR
