| 9
Introduction | AP70/AP80 Installation Manual
AP80, simple system example
TURN
MENUCMD
STBY AUTO NAV WORK
ALARM
T
T
12/24V DC
GYRO
COMPASS
CD100A
CDI80
GS15
IS70/80NSO
AP80 CONTROL UNITNF80
AC80S
AD80/
SD80
THRUSTER
CONTROL
SOLENOID
VALVES
12/24V DC
T
CAN BUS
DROP CABLES
NMEA 0183/
IEC 61162-1/
IEC 61162-2
TERMINATOR
